DISTRIBUTION AMPLIFIERS

    DDF-3101:   Dual Passive Splitter.

              Dual 2 way RF splitters.
              Operates in the frequency range of 0.25 MHz to 300 MHz.
              Suitable for 34/45/270 Mb/s data rates.
              No power required - totally passive.
              Connections made by BNC connectors.

Brochure

User Manual

    DDA-4010:   Single 1 In, 8 Out / Dual 1 In, 4 Out 3G/HD/SD/ASI
                       Reclocking/Non-reclocking Distribution Amplifier.

              Switch selectable for single 1 in, 8 out or dual 1 in, 4 out distribution amplifier operation.
              In-phase reclocked / non reclocked outputs on each amplifier.
              Selectable for either 3G/HD/SD-SDI or ASI applications.
              Automatic output muting on no input.
              Front panel monitoring outputs.
              Front panel indicators provide monitoring of presence of inputs and lock status.
              Automatic changeover to second input on loss of primary input (selectable).
              Optional relay bypass on loss of power.
              SNMP monitoring and control.

Brochure

User Manual

    DDA-4320:   ASI / SDI / STM-1 Path Protection & Distribution Amplifier.

              For use as buffer or distribution amplifier.
              4 x in-phase reclocked outputs.
              Protection switching capability.
              Selectable for either ASI / SDI or STM-1 applications.
              Automatic input equalisation to 250m.
              Automatic output muting on no input.
              Relay bypass on loss of power.
              Front panel indicators provide monitoring of presence of input signal at
                 270 Mb/s (ASI/SDI) or 155 Mb/s (STM-1).
              SNMP monitoring and control.

Brochure

User Manual

    ZDA-4320RH:   Handshake Connection ASI / SDI / STM-1 Data Amplifiers.

              Redundant pair protection switching operation.
              External alarms from each module.
              One output bypass on power loss.

Brochure

User Manual

    IRT-6010-DDA:   openGear Single 1 In, 8 Out / Dual 1 In, 4 Out 3G/HD/SD/ASI
                             Reclocking/Non-Reclocking Distribution Amplifier.

              Switch selectable for single 1 in, 8 out or dual 1 in, 4 out distribution amplifier operation.
              In-phase reclocked / non reclocked outputs on each amplifier.
              Selectable for either 3G/HD/SD-SDI or ASI applications.
              Automatic output muting on no input.
              Front edge indicators provide monitoring of presence of inputs and lock status.
              Automatic changeover to second input on loss of primary input (selectable).
              Optional relay bypass on loss of power.
              DashBoard™ software monitoring and control.


Brochure

User Manual

    IRT-6100-DDF:   openGear Triple Passive Splitter.

              Triple 2 way RF splitters.
              Operates in the frequency range of 0.25 MHz to 300 MHz.
              Suitable for 34/45/270 Mb/s data rates.
              No power required - totally passive.
              Connections made by BNC connectors.
              For mounting within an openGear® frame.


Brochure

User Manual


FIBRE OPTICS

    DTR-1000:   Multi-Channel 3G/HD/SD/ASI + Gigabit Ethernet Fibre Optic Link.

              Transports up to 16 independent 3G-SDI, HD-SDI, SD-SDI or ASI signal rates
                 plus a 1000/100/10Mb/s Ethernet signal on a single fibre.
              Path lengths up to 26 dB optical path loss using 9/125µm single mode fibre.
              DTR-1000 available as either 16 Tx; 16 Rx; 12 Tx + 4 Rx; 12 Rx + 4 Tx;
                 8 Tx + 8 Rx; 8 Rx + 8 Tx; 8 Tx; 8 Rx; 4 Tx + 4 Rx; or 4 Rx + 4 Tx models.
              Secondary DC supply inputs for power supply redundancy.
              Web Browser monitoring and control.

Brochure

User Manual

    DTR-4630:   3G/HD/SD-SDI/ASI Fibre Optic Transceiver.

              Transports 3G-SDI, HD-SDI, SD-SDI or ASI signal rates.
              Single or bi-directional operation possible with independent transmit and receive
                 functions on the one card.
              Path lengths up to 30 dB optical path loss using 9/125µm single mode fibre.
              LED indicators and external alarm contacts.
              Fibre, video and alarm connections at rear.
              Remote monitoring via SNMP.
              Optional on-board WDM optical combiner for use on a single common fibre.

Brochure

User Manual

    DDT-4630 & DDR-4630:   3G/HD/SD-SDI/ASI Fibre Optic Link.

              Transports 3G-SDI, HD-SDI, SD-SDI or ASI signal rates.
              Path lengths up to 30 dB optical path loss using 9/125µm single mode fibre.
              LED indicators and external alarm contacts.
              Fibre, video and alarm connections at rear.
              Automatic changeover switching of input for signal redundancy on Tx.
              Remote monitoring via SNMP.

Brochure

User Manual

    DDT-4632 & DDR-4632:   Dual 3G/HD/SD-SDI/ASI Fibre Optic Link.

              2 independent fibre links.
              Transports 3G-SDI, HD-SDI, SD-SDI or ASI signal rates.
              Path lengths up to 30 dB optical path loss using 9/125µm single mode fibre.
              LED indicators and external alarm contacts.
              Transmitter (Tx) and receiver (Rx) can be used separately with 2 independent
                 single channel fibre Rx and Tx cards.
              Remote monitoring via SNMP.
              Optional on-board WDM optical combiner for use on a single common fibre.

Brochure

User Manual

    DDT-4624 & DDR-4624:   Quad 3G/HD/SD-SDI/ASI Fibre Optic Link.

              4 independent fibre links.
              Transports 3G-SDI, HD-SDI or SD-SDI & ASI signals.
              Hot pluggable fibre connections.
              Various independent wavelength options available for use with a CWDM system.
              Transmitter (Tx) and receiver (Rx) can be used separately with 4 independent
                 single channel fibre Rx and Tx cards.

Brochure

User Manual

    DDT-4634 & DDR-4634:   Quad 3G/HD/SD-SDI/ASI Fibre Optic Link.

              4 independent fibre links.
              Transports 3G-SDI, HD-SDI or SD-SDI & ASI signals.
              Path lengths up to 30 dB optical path loss using 9/125?m single mode fibre.
              LED indicators and external alarm contacts.
              Transmitter (Tx) and receiver (Rx) can be used separately with 4 independent
                 single channel fibre Rx and Tx cards.
              Remote monitoring via SNMP.
              Optional on-board CWDM optical combiner for use on a single common fibre.

Brochure

User Manual

    DDT-4691 & DDR-4691:   ASI / SDI 8 Channel MUX Fibre Link.

              270 Mb/s type signals, such as ASI and SDI, capability.
              Automatic cable equalisation for up to 300m on each input.
              Optical path loss > 27dB.
              External urgent and non-urgent alarms for system monitoring.
              SNMP monitoring module built in.

Brochure

User Manual

    OFP-4010:   Fibre Optic 2x2 Changeover Protection Switch.

              Automatic switching when optical level falls below a settable preset limit.
              External momentary Set/Reset control.
              No path change on power fail.
              Local or remote control.
              Front panel LED status indicators.
              Optional plug in SNMP monitoring and switching module.

Brochure

User Manual

    OFS-4020:   Optical Fibre Switcher.

              5 x 1 optical switcher.
              May be cascaded for expanded operation.
              Wideband operation 1260nm to 1620nm.
              Front panel local control.
              SNMP monitoring and control.

Brochure

User Manual

    IRT-6630-DTR:   openGear 3G/HD/SD-SDI/ASI Fibre Optic Transceiver.

              Transports 3G-SDI, HD-SDI, SD-SDI or ASI signal rates.
              Single or bi-directional operation possible with independent transmit and receive functions
                 on the one card.
              Path lengths up to 30 dB optical path loss using 9/125µm single mode fibre.
              Automatic changeover switching of input for signal redundancy on Tx.
              Optional on-board WDM optical combiner for use on a single common fibre.
              DashBoard™ and SNMP software monitoring and control.


Brochure

User Manual

    IRT-6630-DDT & IRT-6630-DDR:   openGear 3G/HD/SD-SDI/ASI Fibre Optic Link.

              Transports 3G-SDI, HD-SDI, SD-SDI or ASI signal rates.
              Path lengths up to 30 dB optical path loss using 9/125µm single mode fibre.
              Automatic changeover switching of input for signal redundancy on Tx.
              DashBoard™ and SNMP software monitoring and control.


Brochure

User Manual

    IRT-6632-DDT & IRT-6632-DDR:   openGear Dual 3G/HD/SD-SDI/ASI Fibre Optic Link.

              2 independent fibre links.
              Transports 3G-SDI, HD-SDI, SD-SDI or ASI signal rates.
              Transmitter (Tx) and receiver (Rx) can be used separately with 2 independent single
                 channel fibre Rx and Tx cards.
              Path lengths up to 30 dB optical path loss using 9/125µm single mode fibre.
              Optional on-board WDM optical combiner for use on a single common fibre.
              DashBoard™ and SNMP software monitoring and control.


Brochure

User Manual

    IRT-6638-DDT & IRT-6638-DDR:   openGear 8-Channel 3G/HD/SD-SDI/ASI Fibre Optic Link.

              Transports up to 8 independent 3G-SDI, HD-SDI, SD-SDI or ASI signal rates on a single
                 fibre via an on-board CWDM optical combiner.
              Path lengths up to 27 dB optical path loss using 9/125µm single mode fibre.
              Transmitter (Tx) and receiver (Rx) can be used separately with 8 independent
                 single channel fibre Rx and Tx cards via an external CWDM optical combiner.
              DashBoard™ and SNMP software monitoring and control.


Brochure

User Manual

    IRT-6690-DDT & IRT-6690-DDR:   openGear 8 Channel SD-SDI/ASI Fibre Optic Link.

              270 Mb/s type signals, such as ASI and SDI, capability.
              Automatic cable equalisation for up to 300m on each input.
              Optical path loss ≥ 27dB.
              DashBoard™ and SNMP software monitoring and control.


Brochure

User Manual


NETWORK INTERFACE ADAPTERS

    MDC-3661:   2 Mb/s (E1) G.703 / ASI Network Interface Adapter.    (MOQ applies)

              2 Mb/s (E1) G.703 input to ASI output.
              ASI input to 2 Mb/s (E1) G.703 output.
              Selectable ASI program number.
              AIS signal generated when no input is present.

Brochure

User Manual

    MDT-3670:   ASI to ASI & G.703 Network Interface Adapter.

              Wide range of ASI to ASI & G.703 conversions.
              Reed Solomon encoding.
              Interleaving.
              Scrambling.
              Packet length indication.
              Selectable 188 to 204 byte conversion.
              Packet stuffing with or without PCR restamping.

Brochure

User Manual

    MDR-3670:   G.703 to ASI Network Interface Adapter.

              Wide Range of G.703 to ASI conversions.
              E3 or DS3 operation with automatic DS3 De-framing.
              Reed Solomon correction.
              De-interleaving.
              De-scrambling.
              Packet length indication.

Brochure

User Manual

    MMM-4230 & MMX-4230:   4 ASI to G.703 (DS3) Multiplexer / De-Multiplexer.

              Up to 4 ASI and 1 Data stream on one 45 Mb/s G.703 link.
              Input rate stuffing to 45 Mb/s G.703 rate.
              Selectable input maximum data rates.
              Automatic input equalisation up to 300m.
              Suitable for Single Frequency Network (SFN) use.
              Optional SNMP plug-in monitoring and control module.

Brochure

User Manual

    MMM-4682 & MMX-4682:   4 ASI to G.703 (STM-1) Combiner / DeCombiner.

              Up to 4 ASI and 1 Data stream on one 155 Mb/s (STM-1) G.703 electrical or
                 optical link.
              Automatic Input equalisation up to 200m.
              Suitable for Single Frequency Network use.
              Maintains original ASI rate, packet size & coding.

Brochure

User Manual

    MEM-4551:   Ethernet to ASI Network Interface Adapter.

              Ethernet to ASI / ASI to Ethernet conversion.
              Ethernet port automatically set for 10/100/Half/Full operation.
              Automatic MDI/MDI-X port.
              32 ASI rates between 1 Mb/s and 108 Mb/s.
              Optional plug-in SNMP monitoring and control module.

Brochure

User Manual

    MEM-4552:   Gigabit Ethernet to ASI Network Interface Adapter.

              Ethernet to ASI / ASI to Ethernet conversion.
              Ethernet port automatically set for 100 Base-T or 1000 Base T operation.
              Automatic MDI/MDI-X port.
              Selectable ASI rates between 1 Mb/s and 213 Mb/s.

Brochure

User Manual

    MMM-4711 & MMX-4711:   4 ASI to ASI Combiner / DeCombiner.

              Up to 4 ASI streams on one ASI link.
              Units may be cascaded to increase the number of ASI inputs.
              Recovers transmitted ASI signal without any added PCR jitter and with
                 minimal user setup
              Maintains original ASI rate, packet size & coding (energy dispersal scrambling,
                 interleaving or Reed Solomon bytes).
              Suitable for Single Frequency Networks (SFN).

Brochure

User Manual

    MDC-4910:   SMPTE-310 to ASI Network Interface Adapter.

              SMPTE-310M to ASI, ASI to SMPTE-310M on the one card.
              ATSC rates of 8 VSB and 16 VSB supported.
              Automatic Input equalisation up to 200m.

Brochure

User Manual

    IRT-6750-MEM:   openGear ASI / TSoIP (Ethernet) Network Interface Adapter.

              ASI to TSoIP, or TSoIP to ASI conversion.
              Set up as either a Transmitter or Receiver.
              Supports enabling of Forward Error Correction (FEC).
              IP de-jittering.
              UDP or RTP encapsulation.
              DIP switch, DashBoard™ and SNMP software monitoring and control.


Brochure

User Manual


SWITCHERS

    AMS-4172:   3G/HD/SD-SDI, ASI, G.703, Video, Audio Relay Changeover Switch.

              One video and two audio changeover switches in one package.
              Video path suitable for 3G/HD/SD-SDI, Analogue video, ASI,
                 G703 signals @ 2, 8, 34, 45, 144, 155 Mb/s, and unbalanced AES.
              Audio path suitable for 2 balanced, or 4 unbalanced, audio or data signals,
                 and balanced AES.
              Married or independent operation.
              Momentary Set/Reset control.
              No path change on power fail (or board removal - video only).
              Local or remote control.
              SNMP monitoring and control of module.

Brochure

User Manual

    DVS-4080:   3G/HD/SD-SDI / ASI Digital Video Switcher & Router.

              3G-SDI, HD-SDI, SD-SDI or ASI capable.
              8x1 or dual 4x1 switching operation.
              8x2 or 4x2 router setup.
              Automatic muting on loss of inputs.
              Front panel local control with remote control option.
              SNMP monitoring and control.

Brochure

User Manual

    IRT-6170-AMS:   openGear 3G/HD/SD-SDI, ASI, G.703, Video, Audio Relay Changeover Switch.

              One video and two audio changeover switches in one package.
              Video path suitable for 3G/HD/SD-SDI, Analogue Video, ASI, G.703 signals @ 2, 8, 34,
                 45, 144, 155 Mb/s, and unbalanced AES.
              Audio path suitable for 2 balanced, or 4 unbalanced, audio or data signals, and balanced
                 AES.
              Married or independent operation.
              Momentary Set/Reset control.
              No path change on power fail.
              Local or remote control.
              DashBoard™ software monitoring and control.


Brochure

User Manual

    IRT-6170-AVS:   openGear Dual 4x1 / Single 7x1 75Ω Relay Switcher.

              Dual 4 x 1 or single 7 x 1 relay switch.
              75 ohm unbalanced Inputs & Outputs.
              Latching relays.
              Optional Remote Control.
              DashBoard™ software monitoring and control.


Brochure

User Manual

    IRT-6080-DVS:   openGear 3G/HD/SD-SDI / ASI Digital Video Switcher & Router.

              3G-SDI, HD-SDI, SD-SDI or ASI capable.
              8x1 or dual 4x1 switching operation.
              8x2 or 4x2 router setup.
              Automatic muting on loss of inputs.
              Front edge local control with remote control option.
              DashBoard™ software monitoring and control.


Brochure

User Manual
